– 8 –
Electric Model
Component Locator Views
(Continued Next Page)
Inlet Safety Thermostat
Heater Assembly
High Limit Thermostat
Blower Wheel
Blower Motor
(behind frame)
Drum Motor
Dual Idler Pully
Rack Dry Interlock Relay
Outlet Control Backup Thermostat
Rack Dry Thermostat (behind frame)
Outlet Control Thermistor (behind frame)
Triac
Inlet Control Thermistor
Steam Interlock Relay
Vapor Shield
Power Board
Water Fill Timer
Steam Generator
Water Valve
