– 9 –
Gas Model
Inlet Safety Thermostat
High Limit Thermostat
Blower Wheel
Blower Motor
(behind frame)
Drum Motor
Dual Idler Pully
Rack Dry Thermostat (behind frame)
Outlet Control Thermistor (behind frame)
Steam Interlock Relay
Vapor Shield
Power Board
Water Fill Timer
Steam Generator
Water Valve
Inlet Control Thermistor
Outlet Control
Backup Thermostat
Burner Assembly
Rack Dry Calrod
®
Element
(inside combustion chamber)
