GE T60

GE Multilin T60 Transformer Protection System B-19
APPENDIX B B.4 MEMORY MAPPING
B
2199 Breaker Flashover 1 Status Closed A 0 to 4294967295 --- 1 F300 0
219B Breaker Flashover 1 Status Closed B 0 to 4294967295 --- 1 F300 0
219D Breaker Flashover 1 Status Closed C 0 to 4294967295 --- 1 F300 0
219F Breaker Flashover 1 Voltage Pickup Level 0 to 1.5 pu 0.001 F001 850
21A0 Breaker Flashover 1 Voltage Difference Pickup Level 0 to 100000 V 1 F060 1000
21A2 Breaker Flashover 1 Current Pickup Level 0 to 1.5 pu 0.001 F001 600
21A3 Breaker Flashover 1 Pickup Delay 0 to 65.535 s 0.001 F001 100
21A4 Breaker Flashover 1 Supervision Phase A 0 to 4294967295 --- 1 F300 0
21A6 Breaker Flashover 1 Supervision Phase B 0 to 4294967295 --- 1 F300 0
21A8 Breaker Flashover 1 Supervision Phase C 0 to 4294967295 --- 1 F300 0
21AA Breaker Flashover 1 Block 0 to 4294967295 --- 1 F300 0
21AC Breaker Flashover 1 Events 0 to 1 --- 1 F102 0 (Disabled)
21AD Breaker Flashover 1 Target 0 to 2 --- 1 F109 0 (Self-Reset)
21AE Reserved (4 items) --- --- --- F001 0
21B2 ...Repeated for breaker flashover 2
Breaker Arcing Current Actuals (Read Only Non-Volatile) (6 Modules)
21E0 Breaker 1 Arcing Current Phase A 0 to 99999999 kA
2
-cyc 1 F060 0
21E2 Breaker 1 Arcing Current Phase B 0 to 99999999 kA
2
-cyc 1 F060 0
Breaker Arcing Current Actuals (Read Only Non-Volatile) (6 Modules)
21E4 Breaker 1 Arcing Current Phase C 0 to 99999999 kA
2
-cyc 1 F060 0
Breaker Arcing Current Actuals (Read Only Non-Volatile) (6 Modules)
21E6 Breaker 1 Operating Time Phase A 0 to 65535 ms 1 F001 0
21E7 Breaker 1 Operating Time Phase B 0 to 65535 ms 1 F001 0
Breaker Arcing Current Actuals (Read Only Non-Volatile) (6 Modules)
21E8 Breaker 1 Operating Time Phase C 0 to 65535 ms 1 F001 0
21E9 Breaker 1 Operating Time 0 to 65535 ms 1 F001 0
21EA ...Repeated for module number 2
Breaker Arcing Current Actuals (Read Only Non-Volatile) (6 Modules)
21EE ...Repeated for module number 2
Breaker Arcing Current Actuals (Read Only Non-Volatile) (6 Modules)
21F0 ...Repeated for module number 2
Breaker Arcing Current Actuals (Read Only Non-Volatile) (6 Modules)
21F2 ...Repeated for module number 2
Breaker Arcing Current Actuals (Read Only Non-Volatile) (6 Modules)
21F4 ...Repeated for module number 3
21FE ...Repeated for module number 4
2208 ...Repeated for module number 5
2212 ...Repeated for module number 6
Breaker Arcing Current Commands (Read/Write Command) (6 Modules)
2224 Breaker 1 Arcing Current Clear Command 0 to 1 --- 1 F126 0 (No)
2225 Breaker 2 Arcing Current Clear Command 0 to 1 --- 1 F126 0 (No)
2226 Breaker 3 Arcing Current Clear Command 0 to 1 --- 1 F126 0 (No)
2227 Breaker 4 Arcing Current Clear Command 0 to 1 --- 1 F126 0 (No)
2228 Breaker 5 Arcing Current Clear Command 0 to 1 --- 1 F126 0 (No)
2229 Breaker 6 Arcing Current Clear Command 0 to 1 --- 1 F126 0 (No)
Passwords Unauthorized Access (Read/Write Command)
2230 Reset Unauthorized Access 0 to 1 --- 1 F126 0 (No)
Transformer Differential and Restraint (Read Only)
2300 Transformer Reference Winding 1 to 6 --- 1 F001 1
2301 Transformer Differential Phasor Iad Magnitude 0 to 30 pu 0.001 F001 0
2302 Transformer Differential Phasor Iad Angle -359.9 to 0 degrees 0.1 F002 0
2303 Transformer Restraint Phasor Iar Magnitude 0 to 30 pu 0.001 F001 0
2304 Transformer Restraint Phasor Iar Angle -359.9 to 0 degrees 0.1 F002 0
2305 Transformer Differential 2nd Harm Iad Magnitude 0 to 999.9 % fo 0.1 F001 0
Table B–10: MODBUS MEMORY MAP (Sheet 11 of 74)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
