GE Vivid E80

Front End Processor (FEP)
Vivid E80/E90/E95 – Service Manual 5-29
GC091052 Rev. 3
DS2 Green -5V AVEE Lit
DS3 Green +12V Lit
DS4 Green VCC Lit
DS5 Green LVDC Green when probe is present in
connector #2, #3 or #4
DS6 Green +3V3 Lit
DS7 Green DLP_AUX Lit
DS8, DS9, DS10, DS11 AND DS12 ARE DEBUG LEDS FOR PROBE CONNECTOR #4
DS8 Green DLP AUX (-3.3V) Lit when 4V probe is active in
connector #4
DS9 Green DLP +12V Lit when probe is active in connector
#4
DS10 Green DLP LVDC Lit when probe is active in connector
#4
DS11 Green DLP PMX_VPP (+100V) Lit when probe is active in connector
#4
DS12 Green DLP PMX_VNN (-100V) Lit when probe is active in connector
#4
Table 5-4: LEDs on the Relay board (Cont'd)
LED Color Description Comments
