Completing the setup
Vivid E80/E90/E95 – Service Manual 3-19
GC091052 Rev. 3
Electrical specifications
Verification of the Vivid E80/E90/E95’s voltage setting
Verify that the mains voltage specified for the Vivid E80/E90/E95
is available on-site.
The voltage setting for the Vivid E80/E90/E95 is found on a label
near the Mains Power Circuit Breaker on the rear of the Vivid
E80/E90/E95.
Electrical specifications for Vivid E80/E90/E95
In the table below, the electrical specifications for Vivid E80/E90/
E95 includes monitor and on board peripherals.
Connecting a Vivid E80/E90/E95 to the wrong voltage level will
most likely destroy it.
Table 3-9: Electrical specifications for all Vivid E80/E90/E95
models
Voltage 100-240 VAC ±10%
Power Consumption 700W / 770 VA
Frequency 50/60 Hz
