5
Correct installation
Incorrect installation
The back of the flx�go must not be enclosed where water
could gather� The product should be enclosed in a cut out�
The flx�go can be installed facing inside the hot tub either horizontally (1) or vertically (2)� When installed facing in,
the flx�go must be mounted above the water line� It can also be installed facing out like standard keypads (3)� Proper
clearance (1/4" min�) needs to be planned to make sure the hot tub cover does not come into contact with the flx�go�
1
3
2
water
water
Hot tub cover
Hot tub cover
flx�go
flx�go
Installation
1/4" min�
1/4" min�
