7
Installation
Installation notes
Placement of the flx�go should allow for a minimum
clearance of 2�5" behind the keypad to facilitate
installation of the fastening nut�
When installing the flx�go on the hot tub, a minimum angle of 4 degrees must be respected�
Also make sure that the hot tub cover can never get in contact with the keypad glass surface� Sagging of the hot tub
cover needs to be taken into consideration as it ages and accumulates water� Also make sure that the hot tub cover
does not come into contact with the keypad glass surface�
Horizontal Vertical
MINIMUM
CLEARANCE
63.5 mm
2.500"
4°
4°
