Installation
Connecting the flx.go keypad to the hot tub control
Note: Always shut off power before connecting an accessory to hot tub control�
To connect the flx�go keypad, simply insert its connector into the appropriate keypad connector (C Port) inside the hot
tub control enclosure (as illustrated) and route the cable through the strain relief channel�
Strain relief channel
C connector
