Geeetech A10M User Manual

29
SHENZHEN GETECH TECHNOLOGY CO LTD
6 Software setting
6.1 Install driver
Two printing choices for A10M: SD card printing and USB printing.
SD card printing: After leveling, insert the SD card into the slot, and choose a .gcode file to start
printing.
USB printing: Connect the printer and computer with a USB cable to control the printer with
slicing software such as Repetier-Host, Cura, Simplify3D, Slic3r, etc. Because of some unstable
factors such as signal interference, the USB printing prone to fail. So we suggest choosing SD card
printing.
The details of USB printing are as follows:
Firstly, turn on the printer, and connect the printer to computer with a USB cable. Normally, the
computer will automatically search the install driver. The newest communication chip of A10M is
CH340. See picture (6-1).
(Picture 6-1)
If it fails to automatically install the driver in computer, then check whether the driver is installed
successfully or not. Click to choose “My computer>Property>Device manager”.
If it shows the exclamation mark as picture below (6-2), then you need manually install the driver.

Geeetech A10M Specifications

General

Print Technology	Fused Deposition Modeling (FDM)
Build Volume	220 x 220 x 260 mm
Layer Resolution	0.1-0.4 mm
Filament Diameter	1.75 mm
Nozzle Diameter	0.4 mm
Max Extruder Temperature	250°C
Max Hotbed Temperature	100°C
Connectivity	SD card, USB
Number of Extruders	2
Machine Dimensions	478 x 413 x 485 mm
Net Weight	7.8 kg
Filament Compatibility	PLA, ABS, Wood
Display	LCD
Power Supply	24V
