Geeetech Prusa I3 User Manual

Identify the Printed Parts
ID Number
Part Name
Number of
Parts
1
Chassis corners
4
2
Y motor mount
1
3
Y idler
1
4
Y belt holder assembly
1
5
Y belt holder assembly
2
6
Z left bottom
1
7
Z right bottom
1
8
X motor mount
1
9
X idler
1
10
X carriage
1
11
Z right top
1
12
Z left top
1
13
End stopper mount
3
14
Wade’s extruder body
1
15
Wade’s extruder idler
1
16
Wade’s extruder small gear
1
17
Wade’s extruder big gear
1
18
Hotend mounting plate
1

Geeetech Prusa I3 Specifications

General

Build Volume	200 x 200 x 180 mm
Layer Resolution	0.1-0.3 mm
Filament Diameter	1.75 mm
Nozzle Diameter	0.4 mm
Print Technology	FDM (Fused Deposition Modeling)
Connectivity	SD card, USB
Supported Materials	PLA, ABS, Wood
Frame Material	Acrylic
Power Supply	DC 12V
Machine Weight	8 kg
