Geeetech Prusa I3 User Manual

Build the X-Z plate
Required parts
Number
Acrylic main frame
1
Acrylic side panels
2
Nema 17 motor
2
Z left top (no. 12)
1
Z right top (no. 11)
1
Z left bottom (no. 6)
1
Z right bottom (no. 7)
1
M3-16 screw
10
M3 nut
16
M3-10 screw
6
Motor coupler
2
M3-25
6
1. Attach the z left bottom and z right bottom pieces to the acrylic plate with three m3-16 screws each.
Then attach two Nema 17 motors to the z left and z right pieces with three m3-1019 screws each. Attach
a motor coupler to each motor. Make sure the wires from the Nema 17 motors go through the bottom
openings on the acrylic plate. Do not attach the top z pieces yet.

Geeetech Prusa I3 Specifications

General

Build Volume	200 x 200 x 180 mm
Layer Resolution	0.1-0.3 mm
Filament Diameter	1.75 mm
Nozzle Diameter	0.4 mm
Print Technology	FDM (Fused Deposition Modeling)
Connectivity	SD card, USB
Supported Materials	PLA, ABS, Wood
Frame Material	Acrylic
Power Supply	DC 12V
Machine Weight	8 kg
