Page #7 background imageLoading...
Page #7 background image
2
Attach the Y Plate
Required parts
Number
Acrylic bed
1
M3-16 screw
6
M3 nut
6
Y belt holder assembly 1 (no.4)
1
Y belt holder assembly 2(no. 5)
2
M3-10 screw
2
Zip ties
3
GT-2 timing belt
~70cm
Nema-17 motor
1

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Geeetech Prusa I3 and is the answer not in the manual?

Geeetech Prusa I3 Specifications

General IconGeneral
Build Volume200 x 200 x 180 mm
Layer Resolution0.1-0.3 mm
Filament Diameter1.75 mm
Nozzle Diameter0.4 mm
Print TechnologyFDM (Fused Deposition Modeling)
ConnectivitySD card, USB
Supported MaterialsPLA, ABS, Wood
Frame MaterialAcrylic
Power SupplyDC 12V
Machine Weight8 kg
