54
4. CONFIGURATION
4.5.1. PR.OPT - Selecting program
Acronym Scrolling message Submenu Attributes
PR.OPT PROGRAM NUMBER PR.OPT R W
The parameter lets you select the program to be configured. During normal functioning, the controller shows the number
of the program running and its state P.STAT, viewable in the User Configuration menu.
Unit of measurement
: Number
Options: 1...4
4.5.2. FI.STP - Number of first step assigned to program
Acronym Scrolling message Submenu Attributes
FI.STP FIRST STEP OF PROGRAM PR.OPT R W
The parameter lets you select the first step of the program.
Unit of measurement
: Number
Options: 1...12
4.5.3. LA.STP - Number of last step assigned to program
Acronym Scrolling message Submenu Attributes
LA.STP LAST STEP OF PROGRAM PR.OPT R W
The parameter lets you select the last step of the program.
ATTENTION: LA.STP cannot be less than FI.STP.
Unit of measurement
: Number
Options: 1...12
4.5.4. Strt - Restart mode
Acronym Scrolling message Submenu Attributes
Strt RESTART TYPE AFTER POWER-ON PR.OPT R W
The parameter defines program restart mode after Power-on.
Unit of measurement
: -
Options: FI.STP = Program restarts from first step, with setpoint attributed or equal to PV based on the
following parameter RST.SP
ST.STP = Program restarts from condition in which it stopped (last step in execution, setpoint
RSRCH = Program restarts with search for step (see programmer function...).
4.5.5. RST.SP - Type of control after program restart
Acronym Scrolling message Submenu Attributes
RST.SP CONTROL TYPE AFTER RESET PR.OPT R W
The parameter defines the type of control that the controller runs after a reset while waiting for restart.
With RST.SP = On the setpoint takes the value of PV with reset command active.
Unit of measurement
: -
Options: OFF = The controller continues the control, maintaining the active setpoint
On = The setpoint assumes the value of the process variable (PV) by imposing the control
output to zero.
