116
4. CONFIGURATION
4.20.1. F.tiM - Selecting Timer function mode
Acronym Scrolling message Submenu Attributes
F.tiM TIMER FUNCTION TIMER R W
The parameter shows and sets the timer function mode.
The Timer function is explained in detail in paragraph “5.11. Timer” on page 147.
Unit of measurement:
-
Options: ST.STP = Start/Stop Timer
STABL = Stabilization Timer
SWITC = Power-on Timer
4.20.2. St.St - Selecting the Start/Stop timer command
Acronym Scrolling message Submenu Attributes
St.St TIMER START STOP TIMER R W
The parameter shows and sets the “object” that commands timer Start/Stop.
Unit of measurement:
-
Options: IN.DIG = From digital input
ALRM1 = From alarm 1
ALRM2 = From alarm 2
ALRM3 = From alarm 3
ALRM4 = From alarm 4
AL.HB = From HB alarm
SERIA = From serial
4.20.3. S.S.t - Defining the Start/Stop timer command logic
Acronym Scrolling message Submenu Attributes
S.S.t LOGIC TYPE OF TIMER START/STOP TIMER R W
The parameter shows and sets the type of logic used to command timer Start/Stop.
With positive logic, timer start corresponds to “object” active if IN.DIG input active.
With negative logic, timer start corresponds to “object” inactive if IN.DIG input inactive.
Unit of measurement:
-
Options: POSIT = Positive logic
NEGAT = Negative logic
4.20.4. rESE - Selecting the Reset timer command
Acronym Scrolling message Submenu Attributes
rESE TIMER RESET TIMER R W
The parameter shows and sets the “object” that commands Reset of the timer.
Unit of measurement:
-
Options: AUT.RS = For autoreset with timer in Stop
IN.DIG = From digital input with T.RST function
ALRM1 = From alarm 1
ALRM2 = From alarm 2
ALRM3 = From alarm 3
ALRM4 = From alarm 4
AL.HB = From HB alarm
SERIA = From serial
Gefran 650/1250/1350 Temperature Controller – Abbreviated Manual
40524-04 Rev0
