55
4.5.6. WAIT.S - Option to start execution of program
Acronym Scrolling message Submenu Attributes
WAIT.S DEF OF START EXEC PROGRAM PR.OPT R W
Il parametro abilita o disabilita l’esecuzione automatica del reset della base tempi del programma dopo una commutazio-
ne STOP/START.
Unit of measurement
: -
Options: OFF = Disables automatic execution
On = Enables automatic execution
4.5.7. End - Action at end of program
Acronym Scrolling message Submenu Attributes
End CONDITION AT END OF CYCLE PR.OPT R W
The parameter defines what happens when the program in execution ends (last step done).
Unit of measurement
: -
Options: NONE = Nothing happens. The controller continues control
rESE = switching in the RESET state, the control type will depend on the parameter RST.SP
LOOP = The program restarts from the first step
OFF = The program ends and puts the controller in the OFF position, with control output to zero
4.5.8. LIMIT - Limitation of step duration
Acronym Scrolling message Submenu Attributes
LIMIT DEF OF STEP TIMING LIMITATION PR.OPT R W
The parameter enables or disables limitation of step duration. It is useful for quick execution of the program.
Eventuale HBB è disabilitato e l’uscita di controllo è forzate al valore di FAULT.
Unit of measurement
: -
Options: OFF = Disables limitation of step duration
On = Enables limitation of step duration: limits ramp times to 20 seconds and hold times to 10
seconds, in order to have a step time that never exceeds 30 seconds.
4. CONFIGURATION
4.6. PR.STP Submenu - Configuration of program steps
Acronym Scrolling message Password Description
PR.STP STEP DEFINITION Level 1 Lets you configure the steps that make up the program.
The parameters are configured for each step to be used.
The Programmer function must first be enabled with the
MODE menu, parameter PROGR = On.
For more information on configuring the programmer, see
paragraph “5.13. Set point programmer” page 149.
