4.7.7. LO.SCL - Lower limit of scale
Acronym Scrolling message Submenu Attributes
LO.SCL INPUT LOW LIMIT I.MAIN R W
The parameter shows and sets the lower limit of the measurement scale used for the main input, based on input (or sen-
sor) type, unit of measurement, and number of decimals selected.
The upper value of LO.SCL is not limited by the value of HI.SCL
Unit of measurement
: The one set with the Unit parameter
Options: A numerical value within the temperature range of the input or sensor
Unit = °C
DEC.P = 0
Unit = °F
DEC.P = 0
Unit = °C
DEC.P = 0
Unit = °F
DEC.P = 0
J.TC 0...1000 32...1832 4-20M -1999...9999 -1999...9999
K.TC 0...1300 32...2372 10V -1999...9999 -1999...9999
R TC 0...1750 32...3182 2-10V -1999...9999 -1999...9999
S TC 0...1750 32...3182 5V -1999...9999 -1999...9999
T.TC -200...400 -328...752 1-5V -1999...9999 -1999...9999
C.TC 0...2300 32...4172 1V -1999...9999 -1999...9999
D.TC 0...2300 32...4172 0.2-1V -1999...9999 -1999...9999
PT2.TC 0...1880 32...4208 C.RTD -1999...9999 -1999...9999
INFR1 10...70 50...158 C.60MV -1999...9999 -1999...9999
INFR2 60...120 140...248 C.20MA -1999...9999 -1999...9999
INFR3 115...165 239...329 C.4-20 -1999...9999 -1999...9999
INFR4 140...260 284...500 C.10V -1999...9999 -1999...9999
PT100 -200...850 -328...1562 C.2-10 -1999...9999 -1999...9999
PT.LIM -50...100 -58...212 C.5V -1999...9999 -1999...9999
JTP10 -200...600 -328...1112 C.1-5V -1999...9999 -1999...9999
60MV -1999...9999 -1999...9999 C.1V -1999...9999 -1999...9999
20MA -1999...9999 -1999...9999 C.0.2-1 -1999...9999 -1999...9999
4.7.8. HI.SCL - Upper limit of scale
Acronym Scrolling message Submenu Attributes
HI.SCL INPUT HIGH LIMIT I.MAIN R W
The parameter shows and sets the upper limit of the measurement scale used for the main input, based on input (or sen-
sor) type, unit of measurement, and number of decimals selected.
The lower value of HI.SCL is limited by the value of LO.SCL.
Unit of measurement
: The one set with the Unit parameter
Options: A value in the interval corresponding to the input or sensor type (see tables for LO.SCL parameter).
4. CONFIGURATION
Gefran 650/1250/1350 Temperature Controller – Abbreviated Manual
40524-04 Rev0
