ADV200 • Functions description and parameters list 105
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
20.16 2348 Torque ref 1 mon Nm FLOAT 1.0 0.125 10.0 ER FVS
Torque ref 1 monitor in Nm.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
20.17 2384 Torque ref filter ms FLOAT 1.000 0.125 10.000 ERW F_S
Setting of a lter on the torque reference monitoring.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
20.18 2386 Torque ref % perc FLOAT 16/32 0.0 0.0 0.0 ER F_S
Monitoring of the torque reference value in %.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
20.19 2390 Torque ref Nm FLOAT 16/32 0.0 0.0 0.0 ER F_S
Monitoring of the torque reference value in Nm.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
20.20 2394 Torque % perc FLOAT 16/32 0.0 0.0 0.0 ER F_S
Monitoring of the % value of the motor nominal Torque.
Values are available thru analog outputs.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
20.21 2398 Torque Nm FLOAT 0.0 0.0 0.0 ER F_S
Monitoring of the Nm value of the motor nominal Torque.
Values are available thru analog outputs.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
20.22 2366 Torque curr lim Red A FLOAT 16/32BIT CALCF 0.0 CALCF ERWS F_S
Setting of the torque current limit when the 2368 Torque clim Red src command is enabled. The default value
and maximum value are automatically calculated by the drive whenever any changes are made to the motor
plate data and after autotuning.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
20.23 2368 Torque clim Red src LINK 16 6000 0 16384 ERW F_S
Selection of the origin (source) to be used to reduce the torque current limit. When this command is enabled
the torque limit passes to the level set in parameter 2366 Torque curr lim Red. The signals that can be associ-
ated with the function can be selected from the “L_DIGSEL2” selection list.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
20.24 2340 Torque scale factor perc FLOAT 100.00 1.00 200.00 ERW F_S
Scale factor of nominal motor torque in % (Torque %, IPA 2394) to let the user display motor torque in the
required scale.
Scaled torque % = Torque % (IPA 2394) * 100 / Torque scale factor (IPA 2340).
