12 ADV200 • Functions description and parameters list
threshold is reduced to 160%. When the overload level par. 368 Drive overload accum reaches 100%, the
output current threshold is reduced to 100% of the rated current, and stays at that value until the I²t integrator
cycle is complete. At this point the 180% instantaneous overload is re-enabled.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
1.25 3260 Bres overload accum perc UINT16 16/32 0 0 100 ER FVS
The used braking resistor overload limit is displayed (100% = alarm threshold).
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
1.26 1066 Enable state mon BIT 16 0 0 1 R FVS
The drive Enable command status is displayed. Voltage must be present on terminal 7. The FR Forwardstart
command is needed to start the inverter.
0 Disabled drive disabled
1 Enabled drive enabled
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
1.27 1068 Start state mon BIT 16 0 0 1 R FVS
The drive Start command status is displayed.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
1.28 1070 FastStop state mon BIT 16 0 0 1 R FVS
The drive FastStop command status is displayed.
Menu PAR Descripttion UM Type FB BIT Def Min Max Acc Mod
1.29 1100 Digital input mon UINT16 16 0 0 0 R FVS
The status of the digital inputs on the drive is displayed. It can also be read via a serial line or eldbus. The
data are contained in a word, where each bit is 1 if voltage is supplied to the corresponding input terminal.
1 Input enabled.
0 Input disabled.
I.e. :
00000000001
1
Active DI
1Active DI
2
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
1.30 1300 Digital output mon UINT16 0 0 0 R FVS
The status of the digital outputs on the drive is displayed. It can also be read via a serial line or eldbus. The
data are contained in a word, where each bit is 1 if voltage is supplied to the corresponding input terminal.
1 Output enabled.
0 Output disabled.
I.e. :
000000000011
Active DO
1Active
DO 2
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
1.31 1200 Digital input X mon UINT16 16 0 0 0 R FVS
The status of the digital inputs of the expansion card is displayed. It can also be read via a serial line or eld-
bus. The data are contained in a word, where each bit is 1 if voltage is supplied to the corresponding input
terminal. This parameter displays the state of the 16 external inputs. The 14 less signicant bits are displayed
from the keypad.
1 Input enabled.
0 Input disabled.
