ADV200 • Functions description and parameters list 13
I.e. :
000000000011
Active DI
1Active DI
2
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
1.32 1400 Digital output X mon UINT16 0 0 0 R FVS
The status of the digital outputs of the expansion card is displayed. It can also be read via a serial line or
eldbus. The data are contained in a word, where each bit is 1 if voltage is supplied to the corresponding input
terminal.
1 Output enabled.
0 Output disabled.
I.e. :
00000000001
1
Active DO
1Active
DO 2
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
1.33 5400 Dig inp 0Ext mon UINT16 32 0 0 4294967295 ER FVS
This parameter displays the state of external inputs from 0 to 31 through the use of EXP-FL-XCAN-ADV op-
tional card.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
1.34 5402 Dig inp 1Ext mon UINT16 0 0 4294967295 ER FVS
This parameter displays the state of external inputs from 32 to 63 through the use of EXP-FL-XCAN-ADV
optional card.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
1.35 5450 Digital out 0Ext mon UINT16 0 0 0 R FVS
This parameter is used to read the state of external outputs from 0 to 31 through the use of EXP-FL-XCAN-
ADV optional card.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
1.36 5452 Digital out 1Ext mon UINT16 0 0 0 R FVS
This parameter is used to read the state of external outputs from 32 to 63 through the use of EXP-FL-XCAN-
ADV optional card.
