128 ADV200 • Functions description and parameters list
High values allows to perform a faster synchronization but with unwanted braking effects and higher current.
The catch on y may fail if the search voltage is too low.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
22.9.9 3390 Vf catch search curr perc FLOAT 0.6 -1.0 10.0 ERWS V
In the speed searching phase the drive compares the active component of the motor current with this threshold
to detect the achievement of the motor speed. It is expressed as percentage of the rated current . Its default
value is equal to 0.5%. A higher value reduces the search time of the motor speed but the braking effect be-
comes more relevant during the operation.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
22.9.10 3392 Iactive filter ms FLOAT 20.0 1.0 150.0 ERWZ V
This parameter denes the time constant of lter applied to the active component of the motor current.
