ADV200 • Functions description and parameters list 15
2 90.0/110.0 kW 3 690V
3 110.0/132.0 kW 3 690V
4 132.0/160.0 kW 3 690V
5 160.0 kW 3 690V
6 200.0 kW 3 690V
7 250.0 kW 3 690V
8 315.0 kW 3 690V
9 355.0 kW 3 690V
10 400.0 kW 3 690V
11 500.0 kW 3 690V
12 630.0 kW 3 690V
13 710.0 kW 3 690V
14 800.0 kW 3 690V
15 1000.0 kW 3 690V
16 1200.0 kW 3 690V
17 160.0/200.0 kW 3 690V
18 200.0/250.0 kW 3 690V
19 250.0/315.0 kW 3 690V
20 315.0/355.0 kW 3 690V
21 355.0/400.0 kW 3 690V
22 400.0/500.0 kW 3 690V
23 500.0/630.0 kW 3 690V
24 630.0/710.0 kW 3 690V
25 710.0/800.0 kW 3 690V
26 0.9/1.0 MW 3 690V
27 1.0/1.2 MW 3 690V
28 1.35/1.5 MW 3 690V
29 1.65/1.8 MW 3 690V
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
2.3 484 Drive family ENUM No Power 0 0 RS FVS
The available mains voltage is displayed (e.g. 380V...480V for mains 400V). The undervoltage alarm refers to
this voltage value.
The condition No power occurs when the regulation board does not recognize the power board because not
set up properly. The conguration adjustment of a new regulation board is achieved by linking it to a power
board and running a Save parameters.
0 No Power
1 380V…480V
2 500V…575V
3 690V
4 230V
5 380V..480V LC (ADV200-LC)
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
2.4 486 Drive region ENUM EU 0 1 R FVS
The geographical area (Europe or USA) is displayed. The factory settings for the power supply voltage and
frequency used by the drive are dened accordingly.
ADV200-4 ADV200-6
0 EU (400V / 50Hz) EU (690V / 50Hz)
1 USA (460V / 60Hz) USA (690V or 575V / 60Hz)
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
2.5 488 Drive cont current A FLOAT CALCF 0.0 0.0 RZS FVS
The current that the drive can deliver continuously according to size, supply voltage and programmed switching
frequency is displayed.
