ADV200 • Troubleshooting 191
This signal indicates the state of the “machine states” that controls drive operation.
STS_INIT 0
STS_MAGN 1
STS_STOP 2
STS_START 3
STS_FS_STOP 4
STS_FS_START 5
STS_QSTOP 6
STS_FS_MAGN 7
STS_W_QSTOP 8
STS_READY 9
STS_MAGN_START 10
STS_ALM_DISABLED 11
STS_ALM_END_ACTION 12
STS_ALM_STOP 13
STS_ALM_FSTOP 14
STS_ALM_R_TO_NORMAL 15
STS_READY_START 16
STS_READY_FSTOP 17
STS_ALM_NO_RESTART 18
STS_FS_MAGN_START 19
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
1062 Drive OK BIT 16 0 0 1 ER
This signal is active when the drive is in the “OK” condition and no alarms are present.
Connected to the relay output, the normally open relay contact closes when:
- the drive is powered
- no alarm conditions are active.
Note: in the case of parameter 4640 UnderV restart is set to “Enable”, signal remains at the high level if undervoltage condition disap-
pears within the specified time in P4642.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
1064 Drive ready BIT 16 0 0 1 ER
This signal is active when the drive reference is in the “Ready” to run condition.
Connected to the relay output, the normally open relay contact closes when:
- the drive is powered
- preloading is complete
- no alarm conditions are active
- the drive is enabled
- motor magnetisation is complete.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
- 1072 UV Wng&Restart BIT 16 0 0 1 ER
If parameter 4640 UnderV restart is set to “Enable”, when undervoltage condition is detected the drive is
disabled and UV Wng & Restart warning signal is generated. “Drive ok” signal remains at the high level (relay
contacts closed).
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
1110 Digital input E mon BIT 16 0 0 1 ER
1112 Digital input 1 mon BIT 16 0 0 1 ER
1114 Digital input 2 mon BIT 16 0 0 1 ER
1116 Digital input 3 mon BIT 16 0 0 1 ER
1118 Digital input 4 mon BIT 16 0 0 1 ER
