● Speed fbk loss [22] alarm with sinusoidal incremental encoder
Bit
Value
Name
Description
D7..
D4
D3 D2 D1 D0
3 0x8
MOD_
INCR
Cause: voltage level not correct or disturbance on signals of incremental channels
A-B.
Solution: Check the connection of the encoder-drive channels A-B, check the
connection of the screen, check the encoder supply voltage, check parameter 2102
Encoder 1 supply, check parameter 2108 Encoder 1 signal Vpp.
● Speed fbk loss [22] alarm with SinCos encoder
Bit
Value
Name
Description
D7..
D4
D3 D2 D1 D0
3 0x8
MOD_
INCR
Cause: voltage level not correct or disturbance on signals of incremental channels
A-B.
Solution: Check the connection of the the encoder-drive channels A-B, check the
connection of the screen, check the encoder supply voltage, check parameter 2102
Encoder 1 supply, check parameter 2108 Encoder 1 signal Vpp.
4 0x1 0x0 MOD_ABS
Cause: voltage level not correct or disturbance on signals of absolute SinCos chan-
nels.
Solution: Check the connection of the the encoder-drive channels A-B, check the
connection of the screen, check the encoder supply voltage, check parameter 2102
Encoder 1 supply, check parameter 2108 Encoder 1 signal Vpp.
● Speed fbk loss [22] alarm with SSI absolute encoder
Bit
Value
Name
Description
D7..
D4
D3 D2 D1 D0
3 0x8
MOD_
INCR
Cause: voltage level not correct or disturbance on signals of incremental channels
A-B.
Solution: Check the connection of the the encoder-drive channels A-B, check the
connection of the screen, check the encoder supply voltage, check parameter 2102
Encoder 1 supply, check parameter 2108 Encoder 1 signal Vpp.
5 0x2 0x0
CRC_
CKS_P
Cause: SSI signals not present or disturbed.
Solution: Check the connection of the clock and encoder-drive data, check the
connection of the screen, check the encoder supply voltage, check parameter 2102
Encoder 1 supply, check parameter 2112 Encoder 1 SSI bits.
8 0x1 0x0 0x0
Setup
error
Cause: An error occurred during setup.
Solution: Check the connection of the clock and encoder-drive data, check the
connection of the screen, check the encoder supply voltage, check parameter 2102
Encoder 1 supply, check parameter 2112 Encoder 1 SSI bits.
● Speed fbk loss [22] alarm with EnDat absolute encoder
Bit
Value
Name
Description
D7..
D4
D3 D2 D1 D0
3 0x8
MOD_
INCR
Cause: voltage level not correct or disturbance on signals of incremental channels
A-B.
