ADV200 • Troubleshooting 209
Code Name Error description Possible solution
0x00000040 D6 FAULT REGISTER
SIN/COS inputs below LOS (Loss of
Signal) threshold
Check the connection of the Resolver input pins
(SIN-,SIN+,COS-,COS+), check PAR 2124
0x00000080 D7 FAULT REGISTER SIN/COS inputs clipped
Check if any of the Resolver input pins (SIN-
,SIN+,COS-,COS+) are shorted with power input
or ground of the resolver board
C-1.1 Reset Speed fbk loss alarm
The reasons for activating the Speed fbk loss alarm and the information acquired by the encoder are shown in
parameter 2172 SpdFbkLoss code.
If no card has been installed the Speed fbk loss [22] alarm is generated and no cause is displayed in
parameter 2172 SpdFbkLoss code. Several causes may be present at the same time.
If no card is recognised, the system runs a routine that always returns Speed fbk loss [22] active without
specifying a cause.
C-1.2 Encoder error alarm
Setup is performed each time the drive is turned on, regardless of the regulation mode that has been selected.
If an error is detected during setup the Encoder error alarm is generated with the following codes:
Bit
Value
Name
Description
D7..
D4
D3 D2 D1 D0
8 0x1 0x0 0x0
Setup
error
Cause: An error occurred during setup. When this has been signalled the information
obtained from the encoder is not reliable.
Solution: Take the action recommended for Speed fbk loss [22] alarm according to
the type of encoder.
9 0x2 0x0 0x0
Compatibi-
lity error
Cause: Firmware on option card incompatible with firmware on regulation card.
When this has been signalled the information obtained from the encoder is not reli-
able.
Solution: Contact Gefran in order to update the firmware on the optional card.
