gefran ADV200

248 ADV200 • Parameters List
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
7.17 832 Multi ref 0 src LINK 16/32 800 0 16384 RW FVS
L_MLTREF
7.18 834 Multi ref 1 src LINK 16/32 802 0 16384 RW FVS
L_MLTREF
7.19 840 Multi ref sel 0 src LINK 16 6000 0 16384 RW FVS
L_DIGSEL2
7.20 842 Multi ref sel 1 src LINK 16 6000 0 16384 RW FVS
L_DIGSEL2
7.21 844 Multi ref sel 2 src LINK 16 6000 0 16384 RW FVS
L_DIGSEL2
7.22 846 Multi ref sel 3 src LINK 16 6000 0 16384 ERW FVS
L_DIGSEL2
7.23 850 Multi ref sel mon UINT16 0 0 15 R FVS
7.24 852 Multi ref out mon FF INT16 16/32 0 0 0 R FVS
8 - MOTORPOTENTIOMETER
8.1 870 Mpot setpoint FF INT16 16/32 0 CALCI CALCI R FVS
8.2 872 Mpot acceleration s FLOAT 5.0 0.01 1000.0 RW FVS
8.3 874 Mpot deceleration s FLOAT 5.0 0.01 1000.0 RW FVS
8.4 876 Mpot top lim FF INT16 CALCI CALCI CALCI ERW FVS
8.5 878 Mpot bottom lim FF INT16 0 CALCI CALCI ERW FVS
8.6 880 Mpot init cfg ENUM Zero 0 3 ERW FVS
0 Last Power Off
1 Zero
2 Lower Limit
3 Upper Limit
8.7 882 Mpot preset cfg ENUM None 0 11 ERW FVS
0 None
1 Input=0
2 Input=low lim
3 Input&ref=0
4 Input&ref=low
5 Output=0
6 Output=low lim
7 Output&ref=0
8 Output&ref=low
9 Input=upp lim
10 Input&ref=upp
11 Freeze input
8.8 884 Mpot up src LINK 16 6000 0 16384 RW FVS
L_DIGSEL2
8.9 886 Mpot down src LINK 16 6000 0 16384 RW FVS
L_DIGSEL2
8.10 888 Mpot invert src LINK 16 6000 0 16384 ERW FVS
L_DIGSEL2
8.11 890 Mpot preset src LINK 16 6000 0 16384 ERW FVS
L_DIGSEL2
8.12 892 Mpot mode ENUM Fine&Last val 0 3 ERW FVS
0 Ramp&Last val
1 Ramp&Follow
2 Fine&Last val
3 Fine&Follow
8.13 894 Mpot output mon rpm INT16 16/32 0 0 0 ER FVS
