gefran ADV200

ADV200 • Parameters List 247
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
L_MLTREF
6 - RAMPS
6.1 700 Acceleration time 0 s FLOAT 10.0 0.01 1000.0 RW FVS
6.2 702 Deceleration time 0 s FLOAT 10.0 0.01 1000.0 RW FVS
6.3 704 Acceleration time 1 s FLOAT 10.0 0.01 1000.0 ERW FVS
6.4 706 Deceleration time 1 s FLOAT 10.0 0.01 1000.0 ERW FVS
6.5 708 Acceleration time 2 s FLOAT 10.0 0.01 1000.0 ERW FVS
6.6 710 Deceleration time 2 s FLOAT 10.0 0.01 1000.0 ERW FVS
6.7 712 Acceleration time 3 s FLOAT 10.0 0.01 1000.0 ERW FVS
6.8 714 Deceleration time 3 s FLOAT 10.0 0.01 1000.0 ERW FVS
6.9 720 Ramp type ENUM Linear 0 3 ERWZ FVS
0 Linear
1 S-Shape
2 Bypass
3 Off
6.10 722 Multi ramp sel 0 src LINK 16 6000 0 16384 ERW FVS
L_DIGSEL2
6.11 724 Multi ramp sel 1 src LINK 16 6000 0 16384 ERW FVS
L_DIGSEL2
6.12 726 Multi ramp sel mon UINT16 0 0 3 ER FVS
6.13 730 Accel jerk time 0 s FLOAT 1.0 0.02 10.0 ERW FVS
6.14 732 Decel jerk time 0 s FLOAT 1.0 0.02 10.0 ERW FVS
6.15 734 Accel jerk time 1 s FLOAT 1.0 0.02 10.0 ERW FVS
6.16 736 Decel jerk time 1 s FLOAT 1.0 0.02 10.0 ERW FVS
6.17 738 Accel jerk time 2 s FLOAT 1.0 0.02 10.0 ERW FVS
6.18 740 Decel jerk time 2 s FLOAT 1.0 0.02 10.0 ERW FVS
6.19 742 Accel jerk time 3 s FLOAT 1.0 0.02 10.0 ERW FVS
6.20 744 Decel jerk time 3 s FLOAT 1.0 0.02 10.0 ERW FVS
6.21 750 Ramp in zero src LINK 16 6000 0 16384 ERW FVS
L_DIGSEL2
6.22 752 Ramp out zero src LINK 16 6000 0 16384 ERW FVS
L_DIGSEL2
6.23 754 Ramp freeze src LINK 16 3480 0 16384 ERW FVS
L_DIGSEL2
7 - MULTI REFERENCE
7.1 800 Multi reference 0 FF INT16 16/32 0 CALCI CALCI RW FVS
7.2 802 Multi reference 1 FF INT16 16/32 0 CALCI CALCI RW FVS
7.3 804 Multi reference 2 FF INT16 0 CALCI CALCI RW FVS
7.4 806 Multi reference 3 FF INT16 0 CALCI CALCI RW FVS
7.5 808 Multi reference 4 FF INT16 0 CALCI CALCI RW FVS
7.6 810 Multi reference 5 FF INT16 0 CALCI CALCI RW FVS
7.7 812 Multi reference 6 FF INT16 0 CALCI CALCI RW FVS
7.8 814 Multi reference 7 FF INT16 0 CALCI CALCI RW FVS
7.9 816 Multi reference 8 FF INT16 0 CALCI CALCI ERW FVS
7.10 818 Multi reference 9 FF INT16 0 CALCI CALCI ERW FVS
7.11 820 Multi reference 10 FF INT16 0 CALCI CALCI ERW FVS
7.12 822 Multi reference 11 FF INT16 0 CALCI CALCI ERW FVS
7.13 824 Multi reference 12 FF INT16 0 CALCI CALCI ERW FVS
7.14 826 Multi reference 13 FF INT16 0 CALCI CALCI ERW FVS
7.15 828 Multi reference 14 FF INT16 0 CALCI CALCI ERW FVS
7.16 830 Multi reference 15 FF INT16 0 CALCI CALCI ERW FVS
