gefran ADV200

252 ADV200 • Parameters List
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
L_DIGSEL1
13.18 1430 Dig out 1X inversion BIT 0 0 1 RW FVS
13.19 1432 Dig out 2X inversion BIT 0 0 1 RW FVS
13.20 1434 Dig out 3X inversion BIT 0 0 1 RW FVS
13.21 1436 Dig out 4X inversion BIT 0 0 1 RW FVS
13.22 1438 Dig out 5X inversion BIT 0 0 1 RW FVS
13.23 1440 Dig out 6X inversion BIT 0 0 1 RW FVS
13.24 1442 Dig out 7X inversion BIT 0 0 1 RW FVS
13.25 1444 Dig out 8X inversion BIT 0 0 1 RW FVS
13.26 1446 Dig out 9X inversion BIT 0 0 1 RW FVS
14 - ANALOG INPUTS
14.1 1500 Analog input 1 mon cnt INT16 16/32 0 -16384 16384 R FVS
14.2 1502 Analog inp 1 type ENUM -10V..+10V 0 4 RW FVS
0 -10V..+10V
1 0.20mA , 0.10V
2 4..20mA
3 0.1V..10.1V
4 KTY84
14.3 1504 Analog inp 1 scale FLOAT 1.0 -10.0 10.0 RW FVS
14.4 1506 An inp 1 offset tune BIT 0 0 1 RW FVS
14.5 1508 An inp 1 gain tune BIT 0 0 1 RW FVS
14.6 1510 Analog inp 1 filter ms FLOAT 10.0 1.0 1000.0 ERW FVS
14.7 1512 Analog inp 1 top cnt INT16 16384 -32768 +32767 ERW FVS
14.8 1514 Analog inp 1 bottom cnt INT16 -16384 -32768 +32767 ERW FVS
14.9 1516 Analog inp 1 offset cnt INT16 0 -32768 +32767 ERW FVS
14.10 1518 Analog inp 1 gain FLOAT 1.0 -10.0 10.0 ERW FVS
14.11 1520 Analog inp 1 thr cnt INT16 0 -16384 +16384 ERW FVS
14.12 1522 An inp 1 deadband perc FLOAT 0.0 0.0 100.0 ERW FVS
14.13 1524 An inp 1 alt value cnt INT16 16/32 0 -16384 16384 ERW FVS
14.14 1526 An inp 1 sign src LINK 16 6000 0 16384 ERW FVS
L_DIGSEL2
14.15 1528 An inp 1 alt sel src LINK 16 6000 0 16384 ERW FVS
L_DIGSEL2
14.16 1532 Analog input 1 dest ILINK 0 0 0 ER FVS
14.17 1550 Analog input 2 mon cnt INT16 16/32 0 -16384 16384 R FVS
14.18 1552 Analog inp 2 type ENUM -10V..+10V 0 4 RW FVS
0 -10V..+10V
1 0.20mA , 0.10V
2 4..20mA
3 0.1V..10.1V
4 KTY84
14.19 1554 Analog inp 2 scale FLOAT 1.0 -10.0 10.0 RW FVS
14.20 1556 An inp 2 offset tune BIT 0 0 1 RW FVS
14.21 1558 An inp 2 gain tune BIT 0 0 1 RW FVS
14.22 1560 Analog inp 2 filter ms FLOAT 10.0 1.0 1000.0 ERW FVS
14.23 1562 Analog inp 2 top cnt INT16 16384 -32768 +32767 ERW FVS
14.24 1564 Analog inp 2 bottom cnt INT16 -16384 -32768 +32767 ERW FVS
14.25 1566 Analog inp 2 offset cnt INT16 0 -32768 +32767 ERW FVS
14.26 1568 Analog inp 2 gain FLOAT 1.0 -10.0 10.0 ERW FVS
14.27 1570 Analog inp 2 thr cnt INT16 0 -16384 +16384 ERW FVS
14.28 1572 An inp 2 deadband perc FLOAT 0.0 0.0 100.0 ERW FVS
14.29 1574 An inp 2 alt value cnt INT16 16/32 0 -16384 16384 ERW FVS
