ADV200 • Functions description and parameters list 29
references can be selected from those listed in the “L_MLTREF” selection list.
When assigning the reference via terminals, signals with ±10V, 0 ...10V, 0... 20 mA and 4 ... 20 mA can be
used.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
5.19 654 Speed ref invert src LINK 16 6000 0 16384 ERWZ FVS
Selection of the origin (source) of the signal that inverts the speed reference output from the regulator. The termi-
nal that can be used for this function can be selected from among those listed in the “L_DIGSEL2” selection list.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
5.20 660 Speed ref 1 mon FF INT16 0 0 0 ER FVS
5.21 662 Speed ref 2 mon FF INT16 0 0 0 ER FVS
The value of the relative speed reference is displayed.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
5.22 670 Speed ref top lim FF INT32 CALCI 0 CALCI ERWZ FVS
Setting of the upper speed reference limit. If the speed reference exceeds the limits, the motor speed remains
at the set limit value in any case. Speed limits cannot be more than 200% of the value set in the Full scale
speed parameter (REFENCES menu par. 680).
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
5.23 672 Speed ref bottom lim FF INT32 CALCI CALCI 0 ERWZ FVS
Setting of the lower speed reference limit. If the speed reference exceeds the limits, the motor speed remains
at the set limit value in any case. Speed limits cannot be more than 200% of the value set in the Full scale
speed parameter (REFERENCES menu par. 680).
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
5.24 666 Speed ref filter ms UINT16 0 0 1000 ERW FVS
Settting of the lter to the speed reference value. If IPA 666 Speed ref lter is set to 0, lter is disabled.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
5.25 680 Full scale speed rpm INT16 CALCI 50 32000 RWZ FVS
Setting of the reference value for all speed percentage data (References, Speed adaptives ...) corresponding
to 100 % of the actual speed. This parameter can only be changed with the inverter blocked (Enable drive =
Disabled). The recommended setting for the value of this parameter is the motor rated speed. If altered, the
self-tuning procedure should be repeated.
Full scale speed does not dene the maximum possible speed. In any case, the maximum
speed percentage value is ± 200 % of the Full scale speed value.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
5.26 222 Theta ref src LINK 16/32 220 0 16384 ERW F_S
Selection of the origin (source) of the ux reference. It requires the use of the EXP-FL-XCAN-ADV option and it
is needed to manage multi-windings asynchronous motors.
Additional technical informations are available through the Quick startup manual.
Value can be selected from among those listed in the “L_MLTREF” selection list.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
5.27 226 Flux ref mon LINK 16/32 224 0 16384 ERW F_S
Selection of the origin (source) of electrical agle of the motor. It requires the use of the EXP-FL-XCAN-ADV op-
tion and it is needed to manage multi-windings asynchronous motors.
Additional technical informations are available through the Quick startup manual.
Value can be selected from among those listed in the “L_MLTREF” selection list.
