298 ADV200 • Appendix
16-bit module
Signal connected
Module configuration
Variant 1 Variant 2 Variant 3
-10V..+10V -32768..+32767
0V..+10V 0..+65535 0..+32767
4..20mA
• There is no single Unit suitable for all models of analog input module.
Check the scaling provided by the model being used and use the system variables accordingly.
ANALOG INPUT EXP
Name Type Description Unit R/W
sysEAI0 DINT Exp Analog input 0
Scheme: “Analog Inputs Expansion
Card”
4000H * 2^16 = 10V 1600 R
sysEAI1 DINT Exp Analog input 1
Scheme: “Analog Inputs Expansion
Card”
4000H * 2^16 = 10V 1650 R
sysExtIOAnaIn0 INT External expansion analog input 0. Defined by module builder 5410 R
sysExtIOAnaIn1 INT External expansion analog input 1 Defined by module builder 5412 R
sysExtIOAnaIn2 INT External expansion analog input 2 Defined by module builder 5414 R
sysExtIOAnaIn3 INT External expansion analog input 3 Defined by module builder 5416 R
sysExtIOAnaIn4 INT External expansion analog input 4 Defined by module builder 5418 R
sysExtIOAnaIn5 INT External expansion analog input 5 Defined by module builder 5420 R
sysExtIOAnaIn6 INT External expansion analog input 6 Defined by module builder 5422 R
sysExtIOAnaIn7 INT External expansion analog input 7 Defined by module builder 5424 R
• The following table shows the internal and variable system parameters for External digital output exp.
DIGITAL OUTPUT EXP
Name Type Description Unit R/W
sysEDOBitWord DWORD Read only exp digital output word
Scheme: “Digital Outputs”
Null 1400 R
sysExtIODigOut0 DWORD External expansion digital output 0
This parameter displays the state of
the external outputs from 0 to 31.
The state of digital outputs 0...7
from the MDPLC is not actually
available, as it is overwritten by the
drive according to the setting of the
analog output.
Null 5454 RW
sysExtIODigOut1 DWORD External expansion digital output 1
This parameter displays the state of
the external outputs from 32 to 63.
Null 5456 RW
• The following table shows the internal and variable system parameters for External analog output exp.
Analog output modules can have a resolution of 12 to 16 bits and scaling may vary from manufacturer to manu-
facturer.
