ADV200 • Functions description and parameters list 35
7.7 812 Multi reference 6 FF INT16 0 CALCI CALCI RW FVS
7.8 814 Multi reference 7 FF INT16 0 CALCI CALCI RW FVS
7.9 816 Multi reference 8 FF INT16 0 CALCI CALCI ERW FVS
7.10 818 Multi reference 9 FF INT16 0 CALCI CALCI ERW FVS
7.11 820 Multi reference 10 FF INT16 0 CALCI CALCI ERW FVS
7.12 822 Multi reference 11 FF INT16 0 CALCI CALCI ERW FVS
7.13 824 Multi reference 12 FF INT16 0 CALCI CALCI ERW FVS
7.14 826 Multi reference 13 FF INT16 0 CALCI CALCI ERW FVS
7.15 828 Multi reference 14 FF INT16 0 CALCI CALCI ERW FVS
7.16 830 Multi reference 15 FF INT16 0 CALCI CALCI ERW FVS
It is possible to select up to 16 operating frequencies, which can be set in these parameters.
The frequencies are selected using the binary code of the digital inputs programmed using the Multi ref sel 0
src, Multi ref sel 1 src, Multi ref sel 2 src and Multi ref sel 3 src parameters.
References can be set via the keypad, serial line, digital inputs and Fieldbus.
A sign can be given to the references, so that when they are dened so too is the desired direction of rotation.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
7.17 832 Multi ref 0 src LINK 16/32 800 0 16384 RW FVS
7.18 834 Multi ref 1 src LINK 16/32 802 0 16384 RW FVS
Selection of the origin (source) of the drive speed reference signals. The speed reference values can be se-
lected from those listed in the “L_MLTREF” selection list.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
7.19 840 Multi ref sel 0 src LINK 16 6000 0 16384 RW FVS
7.20 842 Multi ref sel 1 src LINK 16 6000 0 16384 RW FVS
7.21 844 Multi ref sel 2 src LINK 16 6000 0 16384 RW FVS
7.22 846 Multi ref sel 3 src LINK 16 6000 0 16384 ERW FVS
Selection of the origin (source) of the signals used to select one of the preset speeds. These parameters can
only be used together in combinations. The terminals that can be used for this function can be selected from
among those listed in the “L_DIGSEL2” selection list.
The following table describes the selection of the Multispeed function:
Active speed ref Multi ref sel 0 src Multi ref sel 1 src Multi ref sel 2 src Multi ref sel 3 src
Multi reference 0 0 0 0 0
Multi reference 1 1 0 0 0
Multi reference 2 0 1 0 0
Multi reference 3 1 1 0 0
Multi reference 4 0 0 1 0
Multi reference 5 1 0 1 0
Multi reference 6 0 1 1 0
Multi reference 7 1 1 1 0
Multi reference 8 0 0 0 1
Multi reference 9 1 0 0 1
Multi reference 10 0 1 0 1
Multi reference 11 1 1 0 1
Multi reference 12 0 0 1 1
Multi reference 13 1 0 1 1
