ADV200 • Functions description and parameters list 39
6 Output = low lim
7 Output & ref = 0
8 Output & ref = low lim
9 Input = upp lim
10 Input & ref = upp lim
11 Freeze input
When set to None, no setting is executed.
Input = 0 sets input = 0 i.e. a temporary reference setting is performed and the previous reference value is
maintained. The output of the Motor potentiometer function varies with the set ramp times. The previous refer-
ence value is restored when the preset command is removed.
Input = low lim sets Inp = low lim i.e. a temporary reference setting is performed and the previous reference
value is maintained. The output of the Motor potentiometer function varies with the set ramp times. The previ-
ous reference value is restored when the preset command is removed.
Input & ref = 0 sets Inp = 0 and Ref = 0 i.e. a denitive reference setting is performed. The output of the Motor
potentiometer function varies with the set ramp times.
Input & ref = low lim sets Inp = low lim and Ref = low lim i.e. a denitive reference setting is performed. The
output of the Motor potentiometer function varies with the set ramp times.
Output = 0 sets Out = 0 i.e. a temporary output setting for the Motor potentiometer function is performed. The
previous reference value is maintained. If the preset command is enabled, the output of the Motor potentiom-
eter function continues to be = 0, if the preset command is not enabled the output of the Motor potentiometer
function varies with the set ramp times.
Output = low lim sets Out = low lim i.e. a temporary setting for the output of the Motor potentiometer function
is performed.The previous reference value is maintained. If the preset command is enabled, the output of the
Motor potentiometer function continues to be = low lim, if the preset command is not enabled the output of the
Motor potentiometer function varies with the set ramp times.
Output & ref = 0 sets Out = 0 i.e. a denitive setting for the output of the Motor potentiometer function is per-
formed.
Output & ref = low lim sets Out = low lim i.e. a denitive setting for the output of the Motor potentiometer func-
tion is performed.
Input = upp lim sets Inp = upp lim i.e. a temporary setting for the reference is performed and the previous ref-
erence value is maintained. The output of the Motor potentiometer function varies with the set ramp times. The
previous reference value is restored when the preset command is removed.
Input & ref = upp lim sets Inp = upp lim and Ref = upp lim i.e. a denitive reference setting is performed. The
output of the Motor potentiometer function varies with the set ramp times.
When Freeze input is set, the Up and Down commands are temporarily disabled.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
8.8 884 Mpot up src LINK 16 6000 0 16384 RW FVS
Selection of the origin (source) of the signal that increases the speed reference of the motor potentiometer with
the set ramp. The terminal to be associated with this function can be selected from the “L_DIGSEL2” selection
list.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
8.9 886 Mpot down src LINK 16 6000 0 16384 RW FVS
Selection of the origin (source) of the signal that decreases the speed reference of the motor potentiometer
with the set ramp. The terminal to be associated with this function can be selected from the “L_DIGSEL2”
selection list.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
8.10 888 Mpot invert src LINK 16 6000 0 16384 ERW FVS
Selection of the origin (source) of the signal that inverts the speed reference of the motor potentiometer. The
