ADV200 • Functions description and parameters list 55
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
11.18 1042 FR forward src LINK 16 1112 0 16384 ERW FVS
Selection of the origin (source) for the FR forwardstart signal. With this command the motor starts to rotate
(with the Enable command enabled). The terminal to be associated with this function can be selected from the
“L_DIGSEL2” selection list.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
11.19 1044 FR reverse src LINK 16 1114 0 16384 ERW FVS
Selection of the origin (source) for the FR reverse signal. With this command the motor reverses the direc-
tion of rotation (with the Enable command enabled). The terminal to be associated with this function can be
selected from the “L_DIGSEL2” selection list.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
11.20 1046 FR *stop src LINK 16 6000 0 16384 ERW FVS
Selection of the origin (source) for the FR stop signal. The terminal to be associated with this function can be
selected from the “L_DIGSEL2” selection list.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
11.21 1048 FR start mon BIT 16 0 0 1 ER FVS
The status of the Start output of the Forward Reverse Control (FRC) block is displayed.
0 Stop
1 Start
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
11.22 1050 FR reverse mon BIT 16 0 0 1 ER FVS
The status of the Reverse output of the Forward Reverse Control (FRC) block is displayed.
0 No Reverse
1 Reverse
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
11.23 1052 FR cdm mon UINT16 0 0 0 ER FVS
The status of the commands of the Forward Reverse Control (FRC) block are displayed.
FR *stop src FR reverse src FR forward src FR cdm mon
0 0 0 0
0 0 1 1
0 1 0 2
0 1 1 3
1 0 0 4
1 0 1 5
1 1 0 6
1 1 1 7
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
11.24 1032 Drv Interlock src LINK 16 6002 0 16384 ERW FVS
This parameter is used to select the origin (source) of the Drv Interlock signal.
The signal to be associated with this function can be selected from the “L_DIGSEL2” selection list.
0 Drive interlock active (Drive disabled)
1 Drive interlock not active (Drive can be enabled)
