ADV200 • Functions description and parameters list 59
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
12.1 1132 Dig inp 1 inversion BIT 0 0 1 RW FVS
12.2 1134 Dig inp 2 inversion BIT 0 0 1 RW FVS
12.3 1136 Dig inp 3 inversion BIT 0 0 1 RW FVS
12.4 1138 Dig inp 4 inversion BIT 0 0 1 RW FVS
12.5 1140 Dig inp 5 inversion BIT 0 0 1 RW FVS
Reversal of the logic status of the function associated with the digital input (e.g. from enabled with +24V signal
to enabled with low signal).
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
12.6 1150 Digital input E dest ILINK 0 0 0 ER FVS
12.7 1152 Digital input 1 dest ILINK 0 0 0 ER FVS
12.8 1154 Digital input 2 dest ILINK 0 0 0 ER FVS
12.9 1156 Digital input 3 dest ILINK 0 0 0 ER FVS
12.10 1158 Digital input 4 dest ILINK 0 0 0 ER FVS
12.11 1160 Digital input 5 dest ILINK 0 0 0 ER FVS
The function to which the associated digital input refers is displayed.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
12.12 1240 Dig inp 1X inversion BIT 0 0 1 RW FVS
12.13 1242 Dig inp 2X inversion BIT 0 0 1 RW FVS
12.14 1244 Dig inp 3X inversion BIT 0 0 1 RW FVS
12.15 1246 Dig inp 4X inversion BIT 0 0 1 RW FVS
12.16 1248 Dig inp 5X inversion BIT 0 0 1 RW FVS
12.17 1250 Dig inp 6X inversion BIT 0 0 1 RW FVS
12.18 1252 Dig inp 7X inversion BIT 0 0 1 RW FVS
12.19 1254 Dig inp 8X inversion BIT 0 0 1 RW FVS
12.20 5540 Dig inp 9X inversion BIT 0 0 1 RW FVS
12.21 5542 Dig inp 10X inversion BIT 0 0 1 RW FVS
12.22 5544 Dig inp 11X inversion BIT 0 0 1 RW FVS
12.23 5546 Dig inp 12X inversion BIT 0 0 1 RW FVS
12.24 5548 Dig inp 13X inversion BIT 0 0 1 RW FVS
12.25 5550 Dig inp 14X inversion BIT 0 0 1 RW FVS
12.26 5552 Dig inp 15X inversion BIT 0 0 1 RW FVS
12.27 5554 Dig inp 16X inversion BIT 0 0 1 RW FVS
These parameters invert the state of the corresponding digital input of the expansion card.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
12.28 1270 Dig input 1X dest ILINK 0 0 0 ER FVS
12.29 1272 Dig input 2X dest ILINK 0 0 0 ER FVS
12.30 1274 Dig input 3X dest ILINK 0 0 0 ER FVS
12.31 1276 Dig input 4X dest ILINK 0 0 0 ER FVS
12.32 1278 Dig input 5X dest ILINK 0 0 0 ER FVS
12.33 1280 Dig input 6X dest ILINK 0 0 0 ER FVS
12.34 1282 Dig input 7X dest ILINK 0 0 0 ER FVS
12.35 1284 Dig input 8X dest ILINK 0 0 0 ER FVS
12.36 5570 Dig input 9X dest ILINK 0 0 0 ER FVS
12.37 5572 Dig input 10X dest ILINK 0 0 0 ER FVS
