62 ADV200 • Functions description and parameters list
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
13.1 1310 Digital output 1 src LINK 16 1062 0 16384 RW FVS
13.2 1312 Digital output 2 src LINK 16 1064 0 16384 RW FVS
13.3 1314 Digital output 3 src LINK 16 946 0 16384 RW FVS
13.4 1316 Digital output 4 src LINK 16 936 0 16384 RW FVS
Selection of the origin (source) of the signal to be assigned to the relative digital output. The functions that can
be associated with the digital outputs are listed in the “L_DIGSEL1” selection list.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
13.5 1330 Dig out 1 inversion BIT 0 0 1 RW FVS
13.6 1332 Dig out 2 inversion BIT 0 0 1 RW FVS
13.7 1334 Dig out 3 inversion BIT 0 0 1 RW FVS
13.8 1336 Dig out 4 inversion BIT 0 0 1 RW FVS
Reversal of the logic status of the function associated with the digital output.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
13.9 1410 Dig output 1X src LINK 16 6000 0 16384 RW FVS
13.10 1412 Dig output 2X src LINK 16 6000 0 16384 RW FVS
13.11 1414 Dig output 3X src LINK 16 6000 0 16384 RW FVS
13.12 1416 Dig output 4X src LINK 16 6000 0 16384 RW FVS
13.13 1418 Dig output 5X src LINK 16 6000 0 16384 RW FVS
13.14 1420 Dig output 6X src LINK 16 6000 0 16384 RW FVS
13.15 1422 Dig output 7X src LINK 16 6000 0 16384 RW FVS
13.16 1424 Dig output 8X src LINK 16 6000 0 16384 RW FVS
13.17 1426 Dig output 9X src LINK 16 6000 0 16384 RW FVS
Selection of the origin (source) of the signal to be assigned to the relative digital output of the expansion card.
The functions that can be associated with the digital outputs are listed in the “L_DIGSEL1” selection list.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
13.18 1430 Dig out 1X inversion BIT 0 0 1 RW FVS
13.19 1432 Dig out 2X inversion BIT 0 0 1 RW FVS
13.20 1434 Dig out 3X inversion BIT 0 0 1 RW FVS
13.21 1436 Dig out 4X inversion BIT 0 0 1 RW FVS
13.22 1438 Dig out 5X inversion BIT 0 0 1 RW FVS
13.23 1440 Dig out 6X inversion BIT 0 0 1 RW FVS
13.24 1442 Dig out 7X inversion BIT 0 0 1 RW FVS
13.25 1444 Dig out 8X inversion BIT 0 0 1 RW FVS
13.26 1444 Dig out 9X inversion BIT 0 0 1 RW FVS
Reversal of the logic status of the function associated with the digital output of the expansion card.
