ADV200 • Functions description and parameters list 77
output assumes the value of 0 - 10V regardless of the sign of the command signal.
0 Disable
1 Enable
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
15.22 1882 Analog out 1X min cnt INT16 -16384 -32768 +32767 ERW FVS
15.23 1884 Analog out 1X max cnt INT16 16384 -32768 +32767 ERW FVS
Setting of the minimum and maximum values for the analog output for the voltage present on analog output 1
of the expansion card.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
15.24 1886 Analog out 1X type ENUM - 0 3 ERW FVS
Selection of the programmed signal on analog output 1 of the expansion card. Depending on the output signal,
move the dedicated switch on the expansion card. The standard output is coded for the signal in voltage.
0 0...20mA
1 4..20mA
2 -10V..+10V
3 0..10V
If set to 0 the analog output sends 0...20mA
If set to 1 the analog output sends 4...20mA
If set to 2 the analog output sends -10..+10V
If set to 3 the analog output sends 0..+10V.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
15.25 1890 Analog out 2X min cnt INT16 -16384 -32768 +32767 ERW FVS
15.26 1892 Analog out 2X max cnt INT16 16384 -32768 +32767 ERW FVS
Setting of the minimum and maximum values for the analog output in current or voltage present on analog
output 2 of the expansion card.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
15.27 1898 Analog out 2X type ENUM -10V..+10V 0 3 ERW FVS
Selection of the programmed signal on analog output 2 of the expansion card. Depending on the output signal,
move the dedicated switch on the expansion card. The standard output is coded for the signal in voltage.
0 0...20mA
1 4..20mA
2 -10V..+10V
3 0..10V
If set to 0 the analog output sends 0...20mA
If set to 1 the analog output sends 4...20mA
If set to 2 the analog output sends -10..+10V
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
15.28 5460 Dig Analog out 0 ext INT16 16 0 -32768 32767 ERW FVS
15.29 5462 Dig Analog out 1 ext INT16 16 0 -32768 32767 ERW FVS
15.30 5464 Dig Analog out 2 ext INT16 16 0 -32768 32767 ERW FVS
15.31 5466 Dig Analog out 3 ext INT16 16 0 -32768 32767 ERW FVS
15.32 5468 Dig Analog out 4 ext INT16 16 0 -32768 32767 ERW FVS
15.33 5470 Dig Analog out 5 ext INT16 16 0 -32768 32767 ERW FVS
15.34 5472 Dig Analog out 6 ext INT16 16 0 -32768 32767 ERW FVS
