96 ADV200 • Functions description and parameters list
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
18.15 2244 Speed reg I dis src LINK 16/32 6000 0 16384 ERW F_S
Selection of the origin (source) of the signal for Enabling/disabling of the Integral part of the Speed regulator (Null=
enabled). The signal to be associated with this function can be selected from the “L_DIGSEL2” selection list.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
18.16 2246 Speed reg P factor perc FLOAT 16/32 0 0 0 ER F_S
Monitor of the proportional component value of the Speed regulator output. It is also available thru analog
output.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
18.17 2248 Speed reg I factor perc FLOAT 16/32 0 0 0 ER F_S
Monitor of the integral component value of the Speed regulator output. It is also available thru analog output.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
18.18 2240 Inertia kgm
2
FLOAT SIZE 0.001 100.0 RWZS F_S
Setting of total inertia of the application with reference to the motor shaft.
Inertia is the tendency of a body at rest to remain at rest or of a body in straight line motion to stay in mo-
tion in astraight line unless acted on by an outside force;
Setting the total system inertia value (motor + mechanical transmission), the drive will set automatically the
PAR 2236 Speed reg P gain proportional gain of the speed regulator in order to react immediatelly to the
speed variations.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
18.19 2242 Bandwidth rad/s FLOAT SIZE 1.0 500.0 RWZS F_S
Setting of the bandwidth.
The bandwidth denes the dynamic performance in terms of capacity of follow the speed references or torque
which the are time variable .
Increasing the value, the drive responce time will increase (automatically will increase PAR 2236 Speed reg P
gain and decrease PAR 2238 Speed reg I time).
Higher value can be used in the case of “rigid” connections between the motor and the machine. Otherwise
you may encounter instability of the system.
