819XX_MAN_GRM-H_11-2022_ENG_pag. 20
2.8. Terminal and conductor table
CONTROL/SIGNAL TERMINALS
Rigid/flexible / cable lug conductor cross section
1 Conductor section
2 Conductors section
1 x 0.2-1.5 mm
2
/
2 x 0.1-0.75 mm
2
1 x 24-16 AWG
2 x 27-19 AWG
Stripping length
8 mm
Nota: Usare conduttori in rame (CU) 60/75°C (140/167°F), rigidi o multifilari
GROUND TERMINAL
Contact area (WxD) screw type
9 x 9 mm
M5
Tightening torque
1,5-2,5 Nm
(13.3 lb-in – 22 lb-in)
VLINE TERMINAL
1 Conductor section
2 Conductors section
1 x 0.2 - 2.5 mm
2
/
2 x 0.5 - 1.5 mm
2
1 x 24 – 12 AWG
2 x 20 - 16 AWG
Stripping length
10 mm
POWER TERMINALS
Rigid/flexible / ferrule conductor cross section
Size
15A 25A 30A 40A 50A 60A 75A 90A 120A
Contact area (WxD) screw type
10,5 x 10,7 mm
M5
Stripping length
13 mm
1 Conductor section
2 Conductors section
1 x 2.5 mm
2
/
2 x 1.5 mm
2
1 x 6 mm
2
/
2 x 4 mm
2
1 x 10 mm
2
/
2 x 6 mm
2
1 x 16 mm
2
/
2 x 10 mm
2
1 x 25 mm
2
/
2 x 16 mm
2
35 mm
2
1 x 50 mm
2
/
2 x 25 mm
2
1 x 14 AWG /
2 x 17 AWG
1 x 10 AWG /
2 x 12 AWG
1 x 8 AWG /
2 x 10 AWG
1 x 6 AWG /
2 x 8 AWG
1 x 4 AWG /
2 x 6 AWG
1 x 3 AWG /
2 x 6 AWG
2 AWG
1 x 1/0 AWG
/ 2 x 3 AWG
Tightening torque
2,5-3 Nm
(22-26,6lb-in)
Note: Use 75°C (167°F) copper (CU), multi-stranded conductors
- (*) The screw terminals are only suitable for on-site wiring connection when the wire is equipped with a tube terminal with eyelet.
It is possible to make ground connection using a copper bar suitably ground connected and fixed to the heatsink of more GRM-H.
