819XX_MAN_GRM-H_11-2022_ENG_pag. 68
5.6.3.3. Minimum non-conduction time to reactivate triggering delay
Acronym App / GF_eXpress menu Attribute Retentive U.M. Default
Description
dL.oF
Power Control R/W
■
ms 5
Minimum non-conduction time to reactivate triggering delay.
min...max: 0 ... 10000 ms
5.6.3.4. Minimum trigger power
Acronym App / GF_eXpress menu Attribute Retentive U.M. Default
Description
Lo.P
Power Control R/W
■
% 0.0
Minimum output power for triggering. Below this % power value, the device does not deliver power.
min...max: 0.0 ... 50.0 %
5.6.3.5. Control output gradient
Acronym App / GF_eXpress menu Attribute Retentive U.M. Default
Description
G.Out
Power Control R/W
■
%/s 0.0
Gradient for the control output, i.e., how quickly the final value is reached. The gradient is defined as a
percentage increment per second in relation to the final value to be achieved.
Set the parameter to 0 to disable the gradient.
min...max: 0.0 ... 200.0 %
Example: By setting the gradient to 50%/s the Ou.P output is not implemented instantaneously
but gradually. If the power goes from 0% to 100%, actuation occurs in a linear ramp of 2 seconds
duration.
