gefran GTF Series User Manual

13
80960G_MHW_GTF_05-2019_ENG
3 • ELECTRICAL CONNECTIONS
3.1 Power connections
RECOMMENDED WIRE GAUGES
Table 6
CURRENT LEVEL
GTF
TERMINAL CABLE WIRE WIRE TERMINAL
TIGHTENING TORQUE /
TOOL
25A 1/L1, 2/T1, PE
4 mm²
10 AWG
Wire terminal / Eye
D. 6mm
2.5 Nm / Phillips screwdriver
PH2 - PH3
40A 1/L1, 2/T1, PE
10 mm²
7 AWG
Wire terminal / Eye
D. 6mm
2.5 Nm / Phillips screwdriver
PH2 - PH3
50A 1/L1, 2/T1, PE
10 mm²
7 AWG
Wire terminal / Eye
D. 6mm
2.5 Nm / Phillips screwdriver
PH2 - PH3
60A 1/L1, 2/T1, PE
16 mm²
5 AWG
Wire terminal / Eye
D. 6mm
2.5 Nm / Phillips screwdriver
PH2 - PH3
75A 1/L1, 2/T1, PE
25 mm²
3 AWG
Wire terminal / Eye
D. 6mm
2.5 Nm / Phillips screwdriver
PH2 - PH3
90A 1/L1, 2/T1, PE
35 mm²
2 AWG
Wire terminal / Eye
D. 6mm
2.5 Nm / Phillips screwdriver
PH2 - PH3
120A 1/L1, 2/T1, PE
50 mm²
1/0 AWG
Wire terminal / Eye
D. 6mm
2.5 Nm / Phillips screwdriver
PH2 - PH3
- 3/L2 (Ref. Vline)
0.25 ...2.5 mm²
23...14 AWG
wire terminal tip
0.5 ...0.6 Nm / Screwdriver blade
0.6 x 3.5 mm
150A 1/L1, 2/T1
70 mm²
2/0 AWG
Wire stripped for 25 mm or
with crimped pre-insulated
terminal tube CEMBRE
PKC70022
6 Nm / No. 6 hex head wrench
200A 1/L1, 2/T1
95 mm²
4/0 AWG
Wire stripped for 25 mm or
with crimped pre-insulated
terminal tube CEMBRE
PKC95025
6 Nm / No. 6 hex head wrench
250A 1/L1, 2/T1
120 mm²
250 AWG
Wire stripped for 25 mm 6 Nm / No. 6 hex head wrench
- 3/L2 (Ref. Vline)
0.25 ...2.5 mm²
23...14 AWG
Wire stripped for 8 mm
or with tag terminal
0.5 ...0.6 Nm / Flat-head screwdriver
tip 0,6 x 3.5 mm
Note:
Cables must be copper “Stranded Wire” or “Compact-Stranded Wire” type with maximum operating temperature 60/75°
