gefran GTF Series User Manual

40
80960G_MHW_GTF_05-2019_ENG
KIT PC USB / RS485 o TTL
kit for PC via the USB port (Windows environment) for GTF standard conguration (TTL
port) for conguration of GTF with the RS485 option
Lets you read or write all of the parameters of a single GTF
A single software for all models
• Easy and rapid conguration
• Saving and management of parameter recipes
• On-line trend and saving of historical data
Component Kit:
- Connection cable PC USB <----> GTF port TTL
- Connection cable PC USB <----> GTF RS485 port
- Serial line converter
- CD SW GF Express installation
ORDERING CODE
GF_eXK-2-0-0....................................Cod. F049095
6.1 accessories
CONFIGURATION KIT
6.2 fuse / fuseholDers
Model
EXTRARAPID FUSES
FUSEHOLDERS
Size
I
2
t
Sign
Form
Model
Code
Power
dissipation @ In
Adoption
Acronym Code
GTF 25
25A
390A² s
FUS-025
10x38
FWC25A10F
338474
6W
PFI-10X38
337134
UR30A@690V
GTF 40...
GTF 50...
50A
1600A² s
FUS-050
22x58
FWP50A22F
338127
9W
PFI-22X58
337223
UR80A@600V
GTF 60...
63A
3080A² s
FUS-063
22x58
FWP63A22F
338191
11W
PFI-22X58
337223
UR80A@600V
GTF 75...
80A
6600A² s
FUS-080
22x58
FWP80A22F
338199
14W
PFI-22X58
337223
UR80A@600V
GTF 90...
125A
6950A² s
FUS-125N
660RF00AT125
338106
25W
PF-DIN
337092
UR400A@1000V
GTF 120...
125A
6950A² s
FUS-125N
660RF00AT125
338106
25W
PF-DIN
337092
UR400A@1000V
GTF 150...
200A
31500A² s
FUS-200S
DN000UB69V200
338930
19W
GTF 200/250
480V/600V
450A
196000A² s
FUS-450S
DN00UB60V450L
338932
17W
GTF 200/250
690V
400A
150000A² s
FUS-400S
DN00UB69V400L
338936
20W
EXTRARAPID FUSE FOR GTS WHEN USED AS A SLAVE OF GTF
Model Fuse Model size
GTS-T 10/230 FWC10A10F 10x38
GTS 15/230, GTS 15/480 FWC16A10F 10x38
GTS 25/480, GTS-T 20/230, GTS-T 25/230 FWC25A10F 10x38
GTS 40/230, GTS 40/480 FWP40A14F 14x51
GTS 50/230, GTS 50/480 FWP63A22F 22x58
GTS 60/230, GTS 60/480, GTS 75/230, GTS 75/480 FWP80A22F 22x58
GTS 90/230, GTS 90/480 FWP100A22F 22x58
GTS 120/230, GTS 120/480 170M1418 000-TN/80
6.2.1 Fuse GG
The electric protection device called FUSE GG must be done in order to grant the protection against the electric cable short cirrcuit
(see EN60439-1, par. 7.5 “Short-circuit protection and short-circuit with stand strength” and 7.6 “Switching devices and components
installed in assemblies”, otherwise the equivalent EN61439-1 paragraphs)
