7
80960G_MHW_GTF_05-2019_ENG
2.4
D
imensions
Fastening may be done on DIN guide (EN50022) or with (5MA). See figures 1 and 2.
All dimensions are expressed in mm.
Figure
1
Depth
143 mm
GTF 75 (Without Fan)
GTF 90 (Without Fan)
GTF 120 (With Fan)
Depth
170.4 mm
GTF50 ((Without Fan)
GTF60 (Without Fan)
GTF 25
GTF 40
2.4.1
T
emplate dimensions
Figure
2
W
L
M5
Models
L
(mm)
W(mm)
GTF 25-40-50-60A:
11
2
44
GTF 75-90-120A:
11
2
11
3
GTF 150-200-250A
287
42
6
8
