gefran SIEIDrive AVy Series User Manual

AVy -HGB
Ch.8 132
Value Access via
Keyp. RS485/ Terminal Opt2-A
min max Factory BUS/ /PDC
Opt2-M
Voltage I [%] 902 Float 0.00 100.00 4.00
R/W - -
Voltage I Nw [%] 909 Float 0.00 100.00 S
R --
Take val part 2a 679 U16 0 65535 -
Z/C - -
Start part 2b 680U16 0 65535 -
C--
P1 flux model 176 Float 0.00 1.00 S
R/W - -
P1 flux model Nw 689 Float S S S
R --
P2 flux model 692U16 120 S
R/W - -
P2 flux model Nw 690U16 SS S
R --
Magnetizing curr [A] 165 Float 0.1 999.0 S
R/W - -
Magnetiz curr Nw [A] 691 Float S S S
R --
Flux P [%] 91 Float 0.00 100.00 S
R/W - -
Flux P Nw [%] 907 Float 0.00 100.00 S
R --
Flux I [%] 92 Float 0.00 100.00 S
R/W - -
Flux I Nw [%] 908 Float 0.00 100.00 S
R --
Voltage P [%] 1022 Float 0.00 100.00 15.00
RW RW-
Voltage P Nw [%] 1024 Float 100.00 0.00 S
RR-
Voltage I [%] 902 Float 0.00 100.00 4.00
R/W - -
Voltage I Nw [%] 909 Float 0.00 100.00 S
R --
Take val part 2b 681U16 0 65535 -
Z/C - -
Fwd-Rev spd tune 1029 U16 1 2 Fwd direction (1)
R/Z - -
Fwd direction 1
Rev direction 2
Test T curr lim [%] 1048 U16 0S 20
R/Z - -
Start part 3 1027 U16 0 65535 -
C--
Inertia [kg*m*m*] 1014 Float 0.0010 999.9990S
R/W - -
Inertia Nw [kg*m*m*] 1030 Float 0.0010 999.9990-
R --
Friction [N*m] 1015 Float 0.000 99.99 S
R/W - -
Friction Nw [N*m] 1031 Float 0.000 99.99 -
R --
Speed P [%] 87 Float 0.00 100.00 S
R/W - -
Speed P Nw [%] 1032 Float 0.00 100.00 -
R --
Speed I [%] 88 Float 0.00 100.00 S
R/W - -
Speed I Nw [%] 1033 Float 0.00 100.00 -
R --
Take val part 3 1028 U16 0 65535 -
Z/C - -
Low speed factor 646 I16 0 32000 5000
R/W - -
Sls speed filter [s] 643 Float 0.01 0.50 0.01
R/W - -
Flux corr factor 647 Float 0.50 1.0 0.90
R/W - -
V/f shape 712 U16 03
V=k
.
f
1.0
(0)
R/Z - -
V=k
.
f
1.0
0
V=k
.
f
1.5
1
V=k
.
f
1.7
2
V=k
.
f
2.0
3
Vlt boost type 709 U16 0 1 Manual (0) R/Z - -
Manual 0
Automatic 1
Manual boost [%] 710 Float 0.0 10.0 1.0
R/W - -
Actual boost [%] 711 Float 0.0 100.0 -
R --
Slip comp type 722 U16 0 1 Manual (0)
R/Z - -
Manual 0
Automatic 1
Manual slip comp [rpm] 723 I16 0 200 0
R/W - -
Actual slip comp [rpm] 724 I16 -400 400 0
R --
Slip comp filt [s] 725 Float 0.003 0.300 0.030
R/W - -
Motor losses % 727 Float 0.0 20.0 0
R/W - -
Spd srch time [s] 893 Float 0.01 10.00 10.00
R/W - -
Flux srch time [s] 894 Float 0.01 20.00 1.00
R/W - -
Spd autocapture [FF] 895I16 -32768 32767 1500
R/W - -
DRIVE PARAMETER \ V/f control
DRIVE PARAMETER \ V/f control \ Voltage boost
DRIVE PARAMETER \ V/f control \ Slip compens
DRIVE PARAMETER \ V/f control \ V/f spd search
DRIVE PARAMETER \ Motor Parameter \ Self-tuning \ Sel-tune 2b
DRIVE PARAMETER \ Motor Parameter \ Self-tuning \ Sel-tune 3
DRIVE PARAMETER \ Sensorless
Parameter No Format
