gefran SIEIDrive AVy Series User Manual

Ch.8131
——— Parameters lists ———
Value Access via
Keyp. RS485/ Terminal Opt2-A
min max Factory BUS/ /PDC
Opt2-M
Dig input term 8 572U16 01 --R - R
Dig input term 9 573U16 01 --R - R
Dig input term 10 574U16 01 --R - R
Dig input term 11 575U16 01 --R - R
Dig input term 12 576 U16 01 - -R - R
Dig input term 13 577 U16 01 - -R - R
Dig input term 14 578 U16 01 - -R - R
Dig input term 15 579 U16 01 - -R - R
Dig input term 16 580U16 01 --R - R
Dig output term 581U16 0 65535 - - R - R
Virtual dig inp 582U16 0
65535 - R/W - R/W
Virtual dig out 583U16 0 65535 -
R - R
Nominal voltage [V] 161 Float 1 999 400
R/Z - -
Nominal speed [rpm] 162 Float** 1 99999 S
R/Z - -
Nom frequency [Hz] 163 Float 1 999 50
R/Z - -
Nominal current [A] 164 Float 0.10 999.00 S
R/Z - -
Cos phi 371 Float 0.1 0.99 S
R/Z - -
Base voltage [V] 167 Float 1 999 400
R/Z - -
Base frequency [Hz] 168 Float 1 999 50
R/Z - -
Take motor par 694U16 01 -
C--
Magnetizing cur [A] 165 Float 0.10 999.00 S
R/W - -
Magn working cur [A] 726 Float 0.10 999.00 S
R --
Rotor resistance [Ohm] 166 Float 0.0001 S S
R/W - -
Stator resist [Ohm] 436 Float 0.0001 S S
R/W - -
Lkg inductance [H] 437 Float 0.00001 9.00000 S
R/W - -
Load motor par 251 U16 0 1 Std400V (0)
Z--
Std for 400V 0
Std for 460V 1
Self tune state 705 U16 0 65535 -
R --
Start part 1 676 U16 0 65535 -
C--
Stator resist [Ohm] 436 Float 0.0001 S S
R/W - -
Stator resist Nw [Ohm] 683 Float S S -
R --
Voltage comp lim [V] 644 Float 0.1 30.0 6.0
R/W - -
Volt comp lim Nw [V] 685 Float 0.1 30.0 -
R --
Comp slope [V/A] 645 Float 0.1 50.0 13.0
R/W - -
Comp slope Nw [V/A] 686 Float 0.1 50.0 -
R --
Lkg inductance [H] 437 Float 0.00001 9.00000 S
R/W - -
Lkg indutance Nw [H] 684 Float S S -
R --
Current P [%] 89 Float 0.00 100.00 S
R/W - -
Current P Nw [%] 687 Float S S -
R --
Rotor resistance [Ohm] 166 Float 0.0001 S S
R/W - -
Rotor resist Nw [Ohm] 682 Float S S -
R --
Current I [%] 90 Float 0.00 100.00 S
R/W - -
Current I Nw [%] 688 Float S S -
R --
Take val part 1 677 U16 0 65535 -
Z/C - -
Start part 2a 678 U16 0 65535 -
C--
P1 flux model 176 Float 0.00 1.00 S
R/W - -
P1 flux model Nw 689 Float S S S
R --
P2 flux model 692U16 120 S
R/W - -
P2 flux model Nw 690U16 SS S
R --
Magnetizing curr [A] 165 Float 0.1 999.0 S
R/W - -
Magnetiz curr Nw [A] 691 Float S S S
R --
Flux P [%] 91 Float 0.00 100.00 S
R/W - -
Flux P Nw [%] 907 Float 0.00 100.00 S
R --
Flux I [%] 92 Float 0.00 100.00 S
R/W - -
Flux I Nw [%] 908 Float 0.00 100.00 S
R --
Voltage P [%] 1022 Float 0 100.00 15.00
RW RW-
Voltage P Nw [%] 1024 Float 100.00 0.00 S
RR-
DRIVE PARAMETER \ Motor Parameter \ Self-tuning
DRIVE PARAMETER \ Motor Parameter \ Self-tuning \ Self-tune 1
DRIVE PARAMETER \ Mot plate data
DRIVE PARAMETER \ Motor Parameter
DRIVE PARAMETER \ Motor Parameter \ Self-tuning \ Self-tune 2a
Parameter No Format
