gefran SIEIDrive AVy Series User Manual

AVy -HGB
Ch.8 130
Value Access via
Keyp. RS485/ Terminal Opt2-A
min max Factory BUS/ /PDC
Opt2-M
Dec delta time [s] 30 U16 0 65535 1
R/W - -
T current lim + [%] 8 U16 0F S
R/W IA R/W
T current lim - [%] 9 U16 0F S
R/W IA R/W
Encoder 1 type 415 I16 0 1 Digital (1)
R/Z - -
Sinusoidal 0
Digital 1
Encoder 1 pulses 416 Float* 600 9999 1024
R/Z - R
Speed base value [FF] 45 U32*** 1 16383 1500
R/Z - R
Save parameters 256 U16 0 65535 -
C--
Enable drive 314 U16 0 1 Disabled (0)
R/W 12 R/W
Enabled 1H
Disabled 0L
Start/Stop 315 U16 0 1 Stop (0)
R/W 13 R/W
Start 1H
Stop 0L
Ramp ref (d) [FF] 109 I16 -32768 32767 -
R - R
Ramp output (d) [FF] 112 I16 -32768 32767 -
R - R
Speed ref (d) [FF] 115 I16 -32768 32767 -
R - R
(Speed ref var)
Actual spd (d) [FF] 119 I16 -32768 32767 -
R - R
(Act spd value)
F act spd (d) [FF] 925 I16 -32768 32767 -
R - R
Act spd filter [s] 923 Float 0.001 0.100 0.001
R/W - -
Ramp ref (rpm) 110 I16 -32768 32767 -
RQA R
Ramp outp (rpm) 113 I16 -32768 32767 -
RQA R
Speed ref (rpm) 118 I16 -32768 32767 -
RQA R
Actual spd (rpm) 122 I16 -8192 8192-
RQA R
Enc1 speed [rpm] 427 I16 -8192 8192-
R - R
Enc2 speed [rpm] 420 I16 -8192 8192-
R - R
F act spd (rpm) 924 I16 -32768 32767 -
RQA R
Act spd filter [rpm] 923 Float 0.001 0.100 0.001
R/W - -
Ramp ref (%) 111 Float -200.0 + 200.0 -
R --
Ramp output (%) 114 Float -200.0 + 200.0 -
R --
Speed ref (%) 117 Float -200.0 + 200.0 -
R --
Actual spd (%) 121 Float -200.0 + 200.0 -
R --
DC link voltage [V] 227 U16 0 999 -
RQA-
Active power [%] 229 Float** -500 500 -
RQA R
Output voltage [V] 233 Float** 0 500 -
RQA R
Output frequency [Hz] 324 Float 0.0 500.0 -
R --
Motor current [A] 231 Float 0.00 S -
RQA-
Torque [%] 230 Float -500 500 -
RQA-
T current ref [%] 41 I16 -500 500 -
RQA R
T curr (%) 927 I16 -500 500 -
RQA R
F T curr (%) 928 I16 -500 500 -
RQA R
T curr filter [s] 926 Float 0.001 0.250 0.100
R/W - -
Flux [%] 234 Float* 0.00 100.00 -
RQA R
Heatsink temp [°C] 881I16 -- -
R --
Regulation temp [°C] 1147 I16 -- -
R --
Intake air temp [°C] 914 U16 -- -
RQA-
Digital I/Q --
R --
Dig input term 564U16 0 65535 -
R - R
Dig input term 1 565U16 01 -
R - R
Dig input term 2 566 U16 01 -
R - R
Dig input term 3 567 U16 01 -
R - R
Dig input term 4 568 U16 01 -
R - R
Dig input term 5 569 U16 01 -
R - R
Dig input term 6 570U16 01 -
R - R
Dig input term 7 571U16 01 -
R - R
MONITOR
MONITOR \ Measurements \ Speed \ Speed in DRC []
Parameter No Format
MONITOR \ Measurements \ Speed \ Speed in rpm
MONITOR \ Measurements \ Speed \ Speed in %
MONITOR \ I/O
MONITOR \ Measurements
