AVy -HGB
Ch.8 134
Value Access via
Keyp. RS485/Terminal Opt2-A
minmaxFactory BUS//PDC
Opt2-M
Acc delta speed [FF] 21 U32 0
2
32
-1
100
Ö
R/W - -
Acc delta time [s] 22 U16 0 65535 1
Ö
R/W - -
Dec delta speed [FF] 29 U32 0
2
32
-1
100
Ö
R/W - -
Dec delta time [s] 30 U16 0 65535 1
Ö
R/W - -
QStp delta speed [FF] 37 U32 0
2
32
-1
1000
Ö
R/W - -
QStp delta time [s] 38 U16 0 65535 1
Ö
R/W - -
Ramp shape 18 U16 0 1Linear (0)
Ö
R/Z - -
Linear 0
S-Shaped 1
S shapetconst [ms] 19 Float 100 3000 500
Ö
R/W - -
Sacctconst [ms]663 Float 100 3000 500
Ö
R/W - -
Sdectconst [ms] 664 Float 100 3000 500
Ö
R/W - -
Ramp +/- delay [ms] 20U16 0 65535
100
Ö
R/W -
Fwd-Rev673U16 03 Fwd(1)
Ö
R/W - R/W
No direction 0
Fwddirection 1
Rev direction 2
No direction 3
Forward sign 293U16 0 1 notsel (0) - R/W ID R/W
FWDselected 1H
FWDnotselected 0 L
Reverse sign 294 U16 0 1 notsel (0) - R/W ID R/W
REV selected 1H
REV notselected 0 L
Enable ramp 245 I16 0 1Enabled (1)
Ö
R/Z - -
Enabled 1
Disabled 0
Rampout = 0344 U16 0 1Not act. (1)
Ö
R/W ID R/W
Actived 0 L
Not Actived 1H
Rampin = 0345U16 0 1Not act. (1)
Ö
R/W ID R/W
Actived 0 L
Not Actived 1H
Freeze ramp 373U16 0 1Not act. (1)
Ö
R/W ID R/W
Actived 0 L
Not Actived 1H
Ramp+ 346 U16 0 1--RQD R
Acc. clockwise + 1H
Dec. counter-clockwise
Other states 0 L
Ramp- 347 U16 0 1--RQD R
Acc. counter-clockwise +
Dec.
clockwise
1H
Other states 0 L
Speed ref[rpm] 118 I16 -32768 32767 -
Ö
RQAR
Speed reg output [% ] 236 I16 - - -
Ö
RQAR
Lock speed reg 322 U16 0 1 OFF (0)
Ö
R/W ID R/W
ON 1L
OFF 0 H
Enablespd reg 242 I16 0 1Enabled (1)
Ö
R/Z - -
Enabled 1
Disabled 0
Lock speed
I 348 U16 0 1Not act. (1)
Ö
R/W ID R/W
Actived 0 L
Not Actived 1H
Aux spd fun sel1016 U16 0 1 Speed up (0)
Ö
R/Z - -
Speed up 0
Inertia-loss cp 1
Prop. filter [ms] 444 U16 0 1000 0
Ö
R/W - -
Parameter No Format
RAMP\Acceleration
RAMP\Deceleration
RAMP\Quick stop
RAMP
SPEED REGULAT.
