Operate the door latch inside the cab
using lever (D, Figure 52) located along
the interior door frame.
Important: If the door is removed for any
reason, make sure to re-connect the door
electrical connection (E, Figure 53) when
the door is replaced.
Operating the machine with the door electrical
connection (E) disconnected can result in damage
to the machine not covered under warranty.
Figure 52 – Cab Interior Door Han-
dle
D
Figure 53 – Cab Door Electrical
Connection
E
