40
# MOT-T1
Pin
Nr..
Motor Temp.1 WR-MPC3-2p
Description
1
Gnd related GND
2
Temp. Mot.1
Motortemperature Sensor 1 (winding
temperature)
# MOT-T2
Pin
Nr..
Motor Temp. 2 WR-MPC3-2p
Description
1 Gnd
related GND
2
Temp. Mot.2 ; function to
parameterize
Motortemperature Sensor 1 (iron temperature)
# ES
Nr.. Emergency Stop WR-MPC3-2p Description
1 supply voltage 3,3V supply voltage for Emergency contact
2
Emergency off Input; ; function to
parameterize (P147)
Emergency off or disabling mc; see parameter
documentation
Pin
Nr..
Slavemodulconnector Sub-D
female 15pole
Conn.
1 Gnd/Schirm
2 PM 2 Temp
3 TxD PM2
4 RxD PM2
5 Treiberpin UH
6 Treiberpin UL
7 Treiberpin VH
8 Treiberpin VL
9 Treiberpin WH
10 Treiberpin WL
11 not used
12 not used
13 not used
14 not used
15 +3,3V
