5. Remove piston 20 from spindle 2.
20
2
16.3 Disassembly for disposal for control
function 3
1. Remove the actuator A (see chapter 12.1
"Removing the actuator").
2. Undo and remove the connecting bolts 23
between the actuator top 10 and the
actuator base 25.
10
25
23
3. Remove actuator top 10.
10
17 Returns
G Clean the valve.
G Request a goods return declaration form
from GEMÜ.
G Returns must be made with a completed
declaration of return.
If not completed, GEMÜ cannot process
credits or
repair work
but will dispose of the goods at the
operator's expense.
Note for returns:
Legal regulations for the protection
of the environment and personnel
require that the completed and
signed goods return declaration
is included with the dispatch
documents. Returned goods can
be processed only when this
declaration is completed.
18 Information
Note on Directive 2014/34/EU
(ATEX Directive):
A supplement to Directive 2014/34/
EU is included with the product if it
was ordered according to ATEX.
Note on staff training:
Please contact us at the address
on the last page for staff training
information.
Should there be any doubts or
misunderstandings in the preceding text,
the German version of this document is the
authoritative document!
