Foundations & Mounting
Installation Guidelines for Spark-Ignited Stationary Emergency Generators 13
Figure 3-2. Combustible Floor and Roof Protection.
Since the entire bottom of the genset is now exposed, it should be covered with a sheet metal plate to keep out small
animals and protect the integrity of the internal parts of the genset. Genset movement is more intense with spring isola-
tion, therefore flexible connections for the fuel and the eletrical conduits are also required.
NOTE: Consult local building codes which may vary
6 Inches
Minimum
6 Inches
Minimum
Generator
Mounting Base
Insulation
Sheet Metal
To Next Page
