Generac Power Systems 0K8420-A User Manual

Installation Drawings
50 Installation Guidelines for Spark-Ignited Stationary Emergency Generators
0K8420-A 25/30 kW (1.5 L) Page 2 of 2
735 (28.9)
776 (30.6)
96 (3.8)
723 (28.5) TYP
MOUNTING SLOT CENTERS
27 (1.0)
TYP
1580 (62.2)
1345 (60.8) 226 (8.9)
STUB-UP AREA
100
(3.9)
50
(1.9)
51
(2.0)
9
(.4)
104.5
(4.1)
674
(26.5)
STUB-UP
AREA
1380 (54.3) TYP
MOUNTING SLOT CENTERS
45 (1.8) TYP
REMOVABLE
STUB-UP COVER
LEFT SIDE VIEW
REAR VIEW
CIRCUIT BREAKER
NEUTRAL AND CUSTOMER
CONNECTION OPENING
HIGH AND LOW
VOLTAGE
STUB-UP AREA
13.5 X 29.5
MOUNTING SLOTS
4X
TOP VIEW
DIMENSIONS: MM [INCH]
